First Choice 3692 CVR Exit Device - Standard & Electric
First Choice 3600 Series CVR Exit Device with Cylinder Prep Kit (Less key cylinder )
The First Choice 3692 Concealed Vertical Rod (CVR) Exit Device delivers high-security performance in a compact design. Designed for narrow stile doors as small as 2" wide, the 3692 is non-handed and available for doors up to 4' wide and 9' tall when used with extended rods.
Available Finishes
• Clear Anodized
• Dark Bronze Anodized
• Black Anodized
Engineered for demanding, high-traffic environments, these durable exit devices are ANSI Grade 1 rated (500,000 cycles) and UL Listed. Attractive anodized finishes are enhanced with high-performance coatings on solid metal end caps for long-lasting durability and appearance.
The 3692 and MEL3692 models are designed to retrofit older Dor-O-Matic crash bars, including:
- Dor-O-Matic 1990 Series
- Dor-O-Matic 1690 Series
The “2” designation in model 3692 indicates that a cylinder prep kit is included for night latch/hold-back functionality with exterior cylinder access. Key cylinder is not included.
Important:
Electric latch retraction panic exit devices require both a power supply and a power transfer. Be sure to order these components separately.
DOWNLOADS
3692 Product Literature
3692 Product Manual / Installation
3600 Series Product Template
PLEASE NOTE: Some of the selections are FACTORY ORDER and can take up to 4 weeks to get. This consists of: 48" Black devices & All 48" MEL Devices.
