Adams Rite 7400 & 7401 Series Electric Strikes
7400 = Flat Face Plate 1-1/4" x 4-7/8"- (Single Door Application)
7401 = Radiused Face Plate 1-1/4" x 4-7/8" -(Pair of Doors Application)
Fail safe or fail secure functions are field selectable.- (Comes packed as fail secure)
Note: Fail safe units should only be operated with DC power.
DOWNLOADS
Data Sheet
Features
- Strike Lip: Basic 7400 strike has lip of proper length for 1-3/4" [44.5 mm] thick door that closes flush with jamb edge. Where door thickness or jamb shape differs from this standard relationship, lip extension kits are available. Lip extension kits not available on 7401, 7431
- Strike Opening: 5/8" adjustable x 1-7/16" x 1/2" deep [15.9 mm adjustable x 36.5 mm x 12.7 mm deep]. Bolt retaining keeper is stainless steel. Strike accepts bolt of Adams Rite 4500, 4700 (discontinued), or 4900 Deadlatch or cylindrical locksets.
- Latchbolt Projection: 1/2" to 5/8”
- Voltage: Field selectable to match power source of 12/24 VDC. VA7400-16 VDC voltage adapter required when using 16 VDC power, available separately. Equipped with a quick connect plug-in type connector
- Preload: 7400 Series Electric Strikes open electrically under 25 lbs [11.3 kg] of preload. Preload is pressure exerted on doors by air conditioning systems, warping or misaligned hardware which can disable common electric strikes. Using jaw inserts of various sizes, the Ultraline 7400 Series electric strikes are adjustable to compensate for door and frame related preload and security problems.
Other finishes and sizes can be ordered. Please give us a call!
